How to replace an ink cartridge using the ink button?(2)

How to replace an ink cartridge using the ink button?(2)

Remove the new ink cartridge from its protective bag. Place the ink cartridge vertically into the

cartridge holder. Then, push the ink cartridge down until it clicks into place. Do not apply excessive

force to the cartridge.
epson ink cartidge
Caution:
Be careful not to break the hooks that are on the side of the ink cartridge when you remove it from
the package.

Do not remove or tear the label on the cartridge; otherwise, ink will leak.
Do not touch the green IC chip on the side of the cartridge. This can damage the ink cartridge.

If an ink cartridge should be removed temporarily from the printer, be sure to protect the ink supply
area of the ink cartridge from dirt and dust. Store the ink cartridge in the same environment as the
printer. When storing the cartridge, be sure that it stands as shown in the illustration below (the label
that identifies the color of the ink cartridge should be displayed on the top of the cartridge). The valve
in the ink supply port is designed to contain any excess ink that may be released. However, careful
handling is recommended. Do not touch the supply port of the ink cartridge or its surrounding area.

Be sure to always install an ink cartridge into the printer immediately following the removal of an old ink
cartridge. Failure to promptly install the ink cartridge may cause the print head to dry out and render it
unable to function properly.
When you are finished replacing the cartridge, close the cartridge cover and the printer cover.
Press the  ink button. The printer moves the print head and begins charging the ink delivery system.
The  ink lights start flashing. This process takes about one minute to complete. When the ink charging process
is finished, the printer returns the print head to its home position. The  power light will stop flashing and remain
on, and the  ink out light will turn off.
epson printer

Caution:
The  power light will continue to flash while the printer is charging ink. Never turn off the printer while this light is
flashing.
Note:
If the ink end error occurs after the print head moves to its home position, the ink cartridge may not be installed
properly. Press the  ink button again, and reinstall the ink cartridge until it clicks into place.

Follow us:

120gsm Sublimation Paper for Epson Sure Color F-series Printing

How to replace an ink cartridge using the ink button?(1)

How to replace an ink cartridge using the ink button?(1)

To replace an ink cartridge using the  ink button, follow the steps below.

1.Make sure that the printer is on. The  power light should be on, but not flashing.
2.Lower the output tray, then open the printer cover.
3.Press the  ink button. The print head moves to the ink cartridge replacement position, the  power
light beginsto flash, and the  ink out light corresponding to the ink cartridge that needs to be replaced
begins to flash or remains on.

Note:
Do not press the  ink button for more than three seconds. The print head cleaning command will
be initiated if the  ink button is pressed for more than three seconds.

Caution:
Do not move or force the print head by hand, as this may damage the printer. Always press the  ink
button to move the print head.

4. Open the cartridge cover. Pinch the sides of the ink cartridge that you want to replace. Lift the
cartridge out of the printer and dispose of it properly. Do not take the used cartridge apart or try to
refill it.

Warning:
If ink gets on your hands, wash them thoroughly with soap and water. If ink gets into your eyes, flus
them immediately with water. If discomfort or vision problems remain after a thorough flushing, see a
doctor immediately.

Note:
For best results, shake the new ink cartridge four or five times before opening the package.

Do not shake the ink cartridge after removing from the bag; this can cause leakage.

Follow us:

How to Replacing an Empty Ink Cartridge from Epson Printer

How to Replacing an Empty Ink Cartridge from Epson Printer

Replacing an Empty Ink Cartridge
This printer uses ink cartridges equipped with IC chips. The IC chips accurately monitor the amount of ink used by each cartridge. Even if a cartridge is removed and later reinserted, ink reserves can be measured and fully utilized. Please note that some ink will be consumed during reliability-confirmation operations each time the cartridge is inserted into the printer.

You can replace an ink cartridge using the printer's control panel or using the Status Monitor utility. Refer to the appropriate section below for instructions.

Warning:
Keep ink cartridges out of the reach of children. Do not allow children to drink from or otherwise handle the cartridges.

Be careful when you handle the used ink cartridges, as there may be some ink surrounding the ink supply port. If ink should come into direct contact with your skin, wash the area thoroughly with soap and water. If ink should come into direct contact with your eyes, flush them immediately with water. If you should feel discomfort or if vision is impaired, see a doctor immediately.

Caution:
EPSON recommends the use of genuine EPSON ink cartridges. Other products not manufactured by EPSON may cause damage to your printer not covered by EPSON's warranties.

Leave the old cartridge installed in the printer until you have obtained a replacement. Otherwise, ink remaining in the print head nozzles may dry out.

Do not refill the ink cartridges. The printer calculates the amount of ink remaining using an IC chip on the ink cartridge. Even if the cartridge is refilled, the amount of ink remaining will not be recalculated by the IC chip and the amount of ink available for use will not change.

Follow us:

Some import tips of Epson Surecolor F-series 6200/6280

The Tips for Epson Surecolor F-series 6200/6280

Features and Benefits
All new Epson inks with High-Density Black formulated for exceptional dye-sublimation transfer
Photographic print quality with resolution up to 720 x 1440 dpi
Revolutionary Epson PrecisionCore TFP printhead designed to work exclusively with Epson UltraChrome DS inks (will not function with other ink systems)
Outstanding everyday production speeds up to 634 ft2 per hour
High Reliability - Developed to Run 24/7

High-Capacity refillable ink cartridges for increased productivity
Includes workflow software by Wasatch®
Built-in Auto Sheet Cutter for industrial roll to cut-sheet media handling
Ideal for flatbed heat transfer press application
One year limited on-site warranty with product registration (warranty coverage is lost if any non-Epson ink system is used)

Epson Rewards
With the purchase of qualifying ink and paper, you can earn and accumulate valuable points, which you can redeem  for rewards.  Click Here for more details.


Epson UltraChrome DS
High-Capacity refillable Ink Tanks - 1.5L per Color
Designed to work exclusively with SureColor F-Series printers
Four color - featuring a High Density Black ink formulation
Vibrant colors, intense blacks, sharp contours, and smooth gradations
Extremely fast drying times
New ink refill packs reduce total cost of ownership

High-Performance MicroPiezo TFP Print Head

Efficient, precise and repeatable performance and excellent image quality
Low vibration meniscus control for highly accurate dot shape and placement
One-inch wide print head with 720 nozzles per color
Ink repelling coating technology for reduced print head maintenance
Optimized specifically for UltraChrome dye-sublimation inks improving the print head life
